MI-T-M WSA-120-0M30 Spray Arch System
Part number: WSA-120-0M30
This item is built or sourced to order. Send us the quantity and specs you need and our team will get you a firm quote and lead time — usually within one business day.
Request a quote
Prefer to talk it through? Contact our team.
- Trade & volume pricing for repeat orders
- Application support from our engineering team
- Fast turnaround on quotes and lead times
This modular spray arch system is designed for high-volume drive-through vehicle wash applications. It features a corrosion-resistant aluminum frame construction suitable for industrial wash environments.
- Soap Flow40gpm
- Wash Flow120gpm
- Undercarriage Flow35gpm
- Rinse Flow70gpm
01Features & Build
-
System Specifications
- Integrated photo-eye activation controls
- Aluminum frame and undercarriage spray bar assembly
- Flush-mounted embedded spray nozzles
- 250-gallon capacity holding tanks
- Configurable build options for specific site requirements
02Specifications14
| Soap Arch GPM @ PSI | 40 @ 30 |
|---|---|
| Wash Arch GPM @ PSI | 120 @ 60 |
| Undercarriage GPM @ PSI | 35 @ 110 |
| Rinse Arch GPM @ PSI | 70 @ 22 |
| Pump | Custom |
| Power Requirements | 230V/460V, 3Ø |
| Spray Bar Dimensions | Custom |
| Pump Frame Dimensions (LxWxH) | 45 x 21 x 67 in. |
| Holding Tank Dimensions (WxH) | 36 x 62 in. |
| Net Weight | 0.00 lbs. |
| Shipping Weight | 0.00 lbs. |
| Length | 0.00 in. |
| Width | 0.00 in. |
| Height | 0.00 in. |
Specifications are supplied by the manufacturer and are subject to change without notice.
03Documents & Downloads1
04Shipping & Ordering
This unit ships crated. Freight costs are calculated based on the final delivery address.
Need a volume price, a fleet configuration, or help matching this machine to your application? Call us and we’ll spec it with you.
