Husqvarna ELITE-DRILL D1610 | 2.000 14CT S D1610 BIT | 547564701
Part Number: 547 56 47-01 (547564701)
The Husqvarna ELITE-DRILL D1610 (Article: 547564701) is a professional-grade diamond core drill bit engineered for high-density, hard to medium-hard concrete applications. This tool is optimized for drill motors with power ratings between 3.5 and 4 hp. For operators prioritizing drilling speed in demanding materials, the bit is also compatible with medium-powered motors ranging from 4 to 5.5 hp. The D1610 is specifically calibrated to maximize the operational efficiency of the Husqvarna DM 1 PACE drill motor.
Product Features
Rooftop design
The shape of the contact surface ensures a smooth, quick start and has self-centering capabilities.
Sturdy design
Durability, reliability, and performance. When your project demands the highest levels of strength and resilience, choose this drill bit.
Wide application window
Optimized for cutting in highly reinforced concrete and abrasive concrete.
Chamfered inside corners
Smoother corners on inside of segments facilitate removal of drill core.
| Product data | |
|---|---|
| Performance level | Gold |
| Assembly | Laser welded |
| Drill connection | 1 1/4"-7 |
| Coolant | Wet |
| Power range, max hp | 4 hp |
| Power range, min hp | 3.5 hp |
| Dimensions | |
| Diameter inch | 2 in |
| Core length inch | 14 in |
| Segment length inch | 0.945 in |
| Segment width inch | 0.137 in |
| Segment height inch | 0.442 in |
| Packaging length (Calc) | 19.016 in |
| Packaging width (Calc) | 2.52 in |
| Packaging height (Calc) | 2.362 in |
| Article gross weight (Calc) | 3.384 lbs |
