Heat Wagon | 950HL Direct Fired Liquid Propane Heater 950,000 BTU/hr
The Heat Wagon 950HL liquid propane model is rated at 950,000 BTU/hr on liquid propane, moving 7,000 CFM. Direct fired heat puts nearly all of the fuel's energy into the space, the economical choice for ventilated job sites, tented work and open structures.
- Output950KBTU/hr
- Airflow7,000CFM
- FuelLP
- Weight325lbs
01Features & Build
-
Features
- Dual fuel – changes from vapor propane to natural gas with the turn of a valve
- CSA approved
- Can be used as a make-up air unit
- Efficient motor reduces amp draw and is rated to run on standard 15 amp circuit
- New remote (50’ long) thermostat with Hi/Lo/Off control
- 12″ wheels make for easy handling
- Relays pull in and hold tight down to 95V
- Ductable up to 100 ft.
- Upgraded heater control board starts heater with low voltage down to 95V-
- potted control board minimizes moisture and vibration
02Specifications14
| Brand | Heat Wagon |
|---|---|
| Model | 950HL |
| Category | Direct Fired |
| Input | 950,000 – 650,000 BTU/Hr |
| Fuel | Liquid propane |
| Fuel Consumption | 10.4 GPH propane / 950 CFH NG |
| Gas Connection | 1-1/4” FNPT |
| Inlet pressure | 10 psi max 1 psi propane min 3 psi NG min |
| Electrical | 120 Volts 15 amp circuit |
| Fan | 7,000 CFM / 1 1/2 HP |
| Thermostat | 2 Stage Hi/Lo/Off w/50’Remote |
| Temp Rise | 250 degrees |
| Weight | 325 lbs. |
| Dimensions | 39″ H 73″ L 30.5″ W |
Specifications are supplied by the manufacturer and are subject to change without notice.
03Downloads2
04Shipping & Ordering
This item ships at approximately 325 lbs. It ships by freight, quoted to the delivery address; contact us for a lift-gate or residential delivery quote before you order.
Need ducting, a thermostat, a regulator or a fuel tank to go with it? See Heat Wagon OEM heater parts or call us and we’ll spec the complete setup with you.
