Allegro 20" x 15' Statically Conductive Ducting - 9650-15EX
This 20-inch diameter, 15-foot long ducting is designed for air handling in hazardous locations where static discharge is a concern. It features a retractable, non-collapsible construction with integrated grounding wires at both ends to safely manage static build-up.
- Diameter20in
- Length15ft
- Resistance1000000ohms/sq in
- Temp Range-65 to 250F
01Features & Build
-
Features
- Constructed from single-ply vinyl and polyester with a neoprene coating.
- Features a Class 1 hard drawn spring steel wire helix.
- Integrated with extended solid grounding wire at each end.
- Rated for temperatures ranging from -65° F to 250° F.
- Designed for dual-direction airflow with low friction loss.
- Meets ASTM 227 specifications and UL94V-0 flame retardant requirements.
- Retractable, non-collapsible design for ease of transport and storage.
- Black finish with black weather-strip.
02Specifications6
| Brand | Allegro |
|---|---|
| Part Number | 9650-15EX |
| Description | 15’ of 20" Statically Conductive Ducting |
| Standard Pack | 1 |
| Country of Origin | United States |
| UPC | 741851965017 |
Specifications are supplied by the manufacturer and are subject to change without notice.
03Applications
04Technical Tips
Pair with a compatible EX Allegro blower and/or storage option
05Related Products3
- 9550-15EX12" x 15' Statically Conductive Ducting
- 9550-25EX12" x 25' Statically Conductive Ducting
- 9650-25EX20" x 25' Statically Conductive Ducting
Other configurations and accessories published for this product.
06Downloads1
07Shipping & Ordering
Ships by ground parcel from stock or direct from the manufacturer.
Need a volume price, a fleet configuration, or help matching this product to your application? Call us and we’ll spec it with you.
