Diamond Products CC2525KCP Propane Saw CC2525KCP Propane Walk Behind Saw CC2525KCP-20 20" - Part # 5801442, Cat # 101516
This walk-behind saw is designed for concrete cutting applications requiring propane power. It accommodates blade diameters up to 26 inches for a maximum cutting depth of 10-3/8 inches.
- Max Depth 144-3/8in
- Max Depth 207-3/8in
- Max Depth 2610-3/8in
- Drive Speed0-130fpm
- Fuel Capacity20lb
01Features & Build
-
Engine and Construction
- Kohler Command EFI engine with propane vapor draw system
- 3/16" steel box frame reinforced with heavy bars
- Two-position tilt handlebars
- Self-propelled drive system
- Screw feed raise and lower mechanism with optional power upgrade
- Cyclone air filter
- Eaton hydrostatic transmission with positive gear drive to rear axle
- Chassis width allows passage through 30" door frames
02Specifications20
| Brand | Diamond Products |
|---|---|
| Model | CC2525KCP |
| Part Number | 5801442 |
| Catalog Number | 101516 |
| Series | CC2525KCP PROPANE WALK BEHIND SAW |
| Model # | CC2525KCP-20 |
| Engine Make/Model | Converted Kohler Command EFI |
| Engine Power | 25 HP |
| Blade Capacity | 20" |
| Weight (lbs.) | 1,030 |
| Max Depth of Cut with 14" Blade | 4-3/8" |
| Max Depth of Cut with 20" Blade | 7-3/8" |
| Max Depth of Cut with 26" Blade | 10-3/8" |
| Blade Shaft Diameter | Varies |
| Arbor Size | 1" with single drive pin |
| Blade Shaft Drive | 5 belts |
| Blade Mounting | Right or left |
| Transmission | Eaton Model 6 |
| Drive Speed | 0-130 feet per minute |
| Fuel Tank Size | 20 pound |
Specifications are supplied by the manufacturer and are subject to change without notice.
03Related Products2
- 5801441CC2525KCP Propane Saw CC2525KCP Propane Walk Behind Saw CC2525KCP-14 14" - Part # 5801441, Cat # 101515
- 5801443CC2525KCP Propane Saw CC2525KCP Propane Walk Behind Saw CC2525KCP-26 26" - Part # 5801443, Cat # 101517
Other configurations and accessories published for this product.
04Downloads2
05Shipping & Ordering
This item ships at approximately 1,030 lbs. Machines ship by freight, quoted to the delivery address; contact us for a lift-gate or residential delivery quote before you order.
