Husqvarna : SB302 HYD BREAKER W/ATTACHMENT Part No. 586501301

$24,245.15

Part Number: 586 50 13-01 (586501301)

The Husqvarna SB 302 (Article 586501301) is a hydraulic breaker engineered specifically for integration with Husqvarna DXR demolition robots. This attachment is designed to deliver consistent impact energy for demanding demolition tasks, ensuring high performance and operational efficiency in controlled environments.

Hydraulics
Hydraulic oil flow	21.13 gal/min
Product data
Impact frequency	23 Hz
Impact energy	610 Joule
Incoming pressure, max	2,175 psi
Operating pressure, max	2,175 psi
Factory option	Standard
Dimensions
Product size length	1,500 in
Product size width	18.1 in
Product size height	16.9 in
Weight	659 lbs
Packaging length (Calc)	47.244 in
Packaging width (Calc)	31.496 in
Packaging height (Calc)	29.134 in
Article gross weight (Calc)	773.823 lbs

586498401 — BLADE BUSHING KIT, SB 302 ATLAS COPCO, ART NO 3315 3019 80
586498501 — LOCKING PIN ATLAS COPCO, ART NO 3315 2031 00
586498601 — RETAINER TOOL ATLAS COPCO ART NO 3315 2030 00
522667901 — SCREW EHHM 16X50 M6S 8.8 ZJSV
522487301 — WASHER NORDLOCK NL16
588608401 — ADAPTER PLATE COMPL SB 302 WELD ASSY
586501301 — BREAKER SB 302
587050201 — BREAKER SB 302 Heat Resistant
589017101 — ADAPTER STRAIGHT O: 1-3/16 - G: 3/4 DUNLOP 1206955
585485304 — HOSE ASSY 1-3/16", 3/4", 1-3/16", ORFS L=1460mm
586512301 — VALVE RESTRICTOR INCL SEALINGS, Ø6,0mm ATLAS COPCO, ART NO 3315 3691 60
510268101 — QUICK COUPLING 3/4" FEMALE PLT4.2519.112
501721203 — WEAR PROTECTION PLASTIC SPIRAL 32mm BLACK L=1300mm
501739602 — WEAR PROTECTION PLASTIC SPIRAL 20mm BLACK L=1300mm
510268001 — QUICK COUPLING 3/4" MALE PLK4.2519.113
589010901 — ADAPTER STRAIGHT O: 9/16 - G: 1/4 DUNLOP 1206956
585484211 — HOSE ASSY 9/16", 1/4", 9/16", ORFS L=1475mm
510267801 — QUICK COUPLING 1/4" MALE PLT1.0606.003
586511201 — SEAL KIT COMPLETE, SB 302 ATLAS COPCO ART NO 3315 3018 90
595082301 — MOIL POINT Moil point (conical) SB 302 SB 302 | 760 mm
586501002 — MOIL POINT Epiroc 3363120265 SB 302 | 760 mm
522869507 — MOIL POINT Extra Long | SB 302
595082501 — CHISEL Chisel (cross) SB 302 SB 302
586501201 — WIDE CHISEL EPIROC 3083319300 SB 302
599390901 — BUSHING PAD SB 302
592946501 — LOCK BUFFER Atlas Copco art. 3315 1419 00
585543101 — HOSE ASSY 1-3/16", 3/4", 1-3/16", ORFS, HEAT COVER L=1460mm
576636903 — LOCKING PIN LOCK PIN FOR HEAT RESISTANT SB202
586498502 — LOCKING PIN FOR HEAT RESISTANT SB302
595082202 — MOIL POINT Moil point (X-Profile) SB 202 SB 202 | 900 mm
586702602 — HEAT PROTECTION KIT SB 202
586702802 — HEAT PROTECTION KIT SB 302
589011001 — ADAPTER STRAIGHT O: 9/16 - G: 3/8 DUNLOP 1206957
536193001 — QUICK COUPLING AIR, MALE, INT G3/8" CEJN 320 eSafe 103205204
585543201 — HOSE ASSY 9/16", 1/4", 9/16", ORFS, HEAT COVER L=1475mm
536196201 — COVER DUST CAP FEMALE CEJN 09 345 1000
583807201 — DUST REDUCTION SB 152
583807202 — DUST REDUCTION SB 202/302
585484210 — HOSE ASSY 9/16", 1/4", 9/16", ORFS L=1420mm
501739603 — WEAR PROTECTION PLASTIC SPIRAL 20mm BLACK L=1500mm
582779901 — ADAPTER STRAIGHT O: 9/16 - O: 9/16 Dunlop 1207586
582035001 — ADAPTER STRAIGHT Int. G 1/4 - Int. O 9/16 DUNLOP 1216248
501720901 — WASHER RUBBER-STEEL 1/4" DUNLOP 1221809
531118354 — NIPPLE 18110 with net
582780001 — NOZZLE WATER OUTLET SB BREAKERS ATLAS COPCO ART 3315 3952 00
