Husqvarna : SB152 HYD BREAKER W/ATTACHMENT Part No. 576189101
Part Number: 576 18 91-01 (576189101)
The Husqvarna SB 152 is a hydraulic breaker designed for integration with compact excavators. Engineered for efficiency and durability, this attachment is suitable for a variety of demolition, renovation, and construction tasks. The unit is built to provide consistent impact energy while maintaining operational stability.
- Article Number: 576189101 / 576 18 91-01
- Compatibility: Optimized for compact excavators
- Application: Demolition, concrete breaking, and site preparation
| Hydraulics | |
|---|---|
| Hydraulic oil flow | 11.88 gal/min |
| Product data | |
| Impact frequency | 32 Hz |
| Impact energy | 254 Joule |
| Incoming pressure, max | 2,175 psi |
| Operating pressure, max | 2,175 psi |
| Factory option | Standard |
| Dimensions | |
| Product size length | 47.6 in |
| Product size width | 15.4 in |
| Product size height | 12.6 in |
| Weight | 326 lbs |
| Packaging length (Calc) | 47.244 in |
| Packaging width (Calc) | 31.496 in |
| Packaging height (Calc) | 15.748 in |
| Article gross weight (Calc) | 264.555 lbs |
- 576189101 — BREAKER SB 152
- 576636801 — BLADE BUSHING BUSHING COMPLETE ATLAS COPCO ART.NO 3315 353 980
- 576636901 — LOCKING PIN LOCK PIN ATLAS COPCO ART.NO 3315 2930 00
- 576637001 — RETAINER TOOL RETAINER ATLAS COPCO ART.NO 3315 147 000
- 522667901 — SCREW EHHM 16X50 M6S 8.8 ZJSV
- 522487301 — WASHER NORDLOCK NL16
- 522808901 — SCREW EHHM 16x70 M6S
- 501739204 — WEAR PROTECTION PLASTIC SPIRAL 25mm BLACK L=1850mm
- 589016601 — ADAPTER STRAIGHT O: 1 - G: 3/4 DUNLOP 1207959
- 510268101 — QUICK COUPLING 3/4" FEMALE PLT4.2519.112
- 585483303 — HOSE ASSY 1", 1/2", 1", ORFS L=1420mm
- 589016401 — ADAPTER STRAIGHT O: 1 - G: 1/2 DUNLOP 1208010
- 522669701 — LOCK NUT M16 NYLOC BLACK CHROMATED
- 588611401 — ADAPTER PLATE COMPL SB 152 WELD ASSY
- 525840201 — PROTECTION TOOL FIXING
- 587094001 — SCREW IHSCM M10x30 8.8 ZJSV ESLOK
- 522671701 — WASHER 10.5X20X2 BRB HB200 ZJS
- 510268001 — QUICK COUPLING 3/4" MALE PLK4.2519.113
- 589010901 — ADAPTER STRAIGHT O: 9/16 - G: 1/4 DUNLOP 1206956
- 585484210 — HOSE ASSY 9/16", 1/4", 9/16", ORFS L=1420mm
- 510267801 — QUICK COUPLING 1/4" MALE PLT1.0606.003
- 501739603 — WEAR PROTECTION PLASTIC SPIRAL 20mm BLACK L=1500mm
- 576637101 — SEAL SEAL KIT ATLAS COPCO ART.NO 3315 290 590
- 595082101 — MOIL POINT Moil point (conical) SB 152 SB 152
- 536841401 — TOOL LONG, MOIL POINT, EPIROPC SB152 MOIL, POINT L = 750mm
- 522869505 — MOIL POINT Extra Long | SB 152
- 576633502 — CHISEL NARROW CHISEL ATLAS COPCO 383 317 SB 152
- 576633503 — WIDE CHISEL WIDE CHISEL ATLAS COPCO 383 3171 SB 152
- 590152501 — BUSHING PAD SB 152
- 592946501 — LOCK BUFFER Atlas Copco art. 3315 1419 00
- 536831701 — HOSE ASSY 1", 1/2", 1", ORFS, HEAT COVER L=1420mm
- 585543203 — HOSE ASSY 9/16", 1/4", 9/16", ORFS, HEAT COVER L=1420mm
- 536193001 — QUICK COUPLING AIR, MALE, INT G3/8" CEJN 320 eSafe 103205204
- 536833601 — SPRING PIN SB152, HEAT EPIROC 0108169126
- 536196301 — COVER DUST CAP MALE CEJN 09 325 1050
- 589011001 — ADAPTER STRAIGHT O: 9/16 - G: 3/8 DUNLOP 1206957
- 536321501 — HEAT PROTECTION KIT SB 152
- 583807201 — DUST REDUCTION SB 152
- 583807202 — DUST REDUCTION SB 202/302
- 585484211 — HOSE ASSY 9/16", 1/4", 9/16", ORFS L=1475mm
- 501739602 — WEAR PROTECTION PLASTIC SPIRAL 20mm BLACK L=1300mm
- 582779901 — ADAPTER STRAIGHT O: 9/16 - O: 9/16 Dunlop 1207586
- 582035001 — ADAPTER STRAIGHT Int. G 1/4 - Int. O 9/16 DUNLOP 1216248
- 501720901 — WASHER RUBBER-STEEL 1/4" DUNLOP 1221809
- 531118354 — NIPPLE 18110 with net
- 582780001 — NOZZLE WATER OUTLET SB BREAKERS ATLAS COPCO ART 3315 3952 00
576633502
Chisel cross
576633503
Chisel wide
595082101
Chisel moil point
583807201
Dust reduction kit hydraulic tools
