Husqvarna : GRAPPLER TOOL ASSY MG100 Part No. 586742901
Part Number: 586 74 29-01 (586742901)
The Husqvarna MG 100 multi grapple is engineered for the DXR 140 and DXR 145 demolition robots. This attachment is designed to provide a high gripping volume while maintaining a low operating weight, optimizing the efficiency of demolition tasks. The unit features a hydraulic rotary drive and is constructed with carbon steel for the grapple and wear components to ensure durability under demanding conditions.
- Article Number: 586742901 / 586 74 29-01
- Material: Carbon steel construction for grapple and wear parts
- Drive System: Hydraulic rotary drive
- Maintenance: Equipped with replaceable blades
- Compatibility: Designed for Husqvarna DXR 140 and DXR 145 models
| Hydraulics | |
|---|---|
| Hydraulic oil flow | 3.96 gal/min |
| Product data | |
| Rotation angle | 360 ° |
| Incoming pressure, max | 4,351 psi |
| Operating pressure, max | 3,626 psi |
| Dimensions | |
| Jaw depth | 8.1 in |
| Jaw width | 12.2 in |
| Jaw opening, min | 0 in |
| Jaw opening, max | 23.6 in |
| Volume | 7.9 gal (US) |
| Product size length | 37.5 in |
| Product size width | 23.8 in |
| Product size height | 15.1 in |
| Weight | 220 lbs |
| Packaging length (Calc) | 47.244 in |
| Packaging width (Calc) | 31.496 in |
| Packaging height (Calc) | 15.748 in |
| Article gross weight (Calc) | 284.837 lbs |
- 587238201 — SCREW EHHM M16x65 8.8 FZB
- 522671901 — WASHER 17X30X3 BRB HB200 ZJSV
- 546009601 — ADAPTER PLATE SB 52
- 522669701 — LOCK NUT M16 NYLOC BLACK CHROMATED
- 546898601 — PROTECTION GRAPPLER DXR 95
- 576744101 — WASHER NORDLOCK NL8
- 725245371 — SCREW EHHM M8x25 8.8 ZPB
- 588615801 — ADAPTER PLATE COMPL MG 100 WELD ASSY
- 501721206 — WEAR PROTECTION PLASTIC SPIRAL 32mm BLACK L=800mm
- 501721202 — WEAR PROTECTION PLASTIC SPIRAL 32mm BLACK L=1450mm
- 510267901 — QUICK COUPLING 1/4" FEMALE PLT1.0606.002
- 576373401 — QUICK COUPLING FEMALE 3/8" PLT1.1310.002
- 510267801 — QUICK COUPLING 1/4" MALE PLT1.0606.003
- 576373201 — QUICK COUPLING 3/8" MALE PLK4.1310.113
- 589010901 — ADAPTER STRAIGHT O: 9/16 - G: 1/4 DUNLOP 1206956
- 589015401 — ADAPTER STRAIGHT O: 11/16 - G: 3/8 DUNLOP 1207574
- 585484216 — HOSE ASSY 9/16", 1/4", 9/16", ORFS L=1040mm
- 588991801 — HOSE ASSY 11/16", 45°, 1/4", 11/16", ORFS L=1505mm
- 501616601 — ADAPTER 45° O: 11/16 - G: 1/2 DUNLOP 1210804
- 586752201 — ROTOR INCL. SEAL KIT, MG 100 Atlas Copco, art no. 3363 1061 24
- 536907201 — QUICK COUPLING 1/2" MALE
- 510268001 — QUICK COUPLING 3/4" MALE PLK4.2519.113
- 574243801 — QUICK COUPLING 1/2" FEMALE - ISO 12.5 PLT4.2013.112
- 510268101 — QUICK COUPLING 3/4" FEMALE PLT4.2519.112
- 589015501 — ADAPTER STRAIGHT O: 11/16 - G: 1/2 DUNLOP 1207996
- 586767201 — ADAPTER SOG 1112
- 501648503 — HOSE ASSY Banjo G1/4", 3/8", 11/16", ORFS L=1260mm
- 587062001 — HOSE ASSY 1/4", 90° BANJO, 3/8", 11/16" L=1645mm
- 501720901 — WASHER RUBBER-STEEL 1/4" DUNLOP 1221809
- 589021901 — SCREW BANJO, G: 1/4" DUNLOP 1210366
- 586751401 — SEAL KIT ROTOR, MG 100 Atlas Copco, art no. 3363 1061 28
- 586750701 — BLADE BUSHING Atlas Copco, art no. 3363 1061 06
- 586749301 — BLADE BUSHING Atlas Copco, art no. 3363 1061 04
- 586752401 — WEAR PLATE KIT, MG 100 Atlas Copco, art no. 3363 1061 23
- 586751101 — SEAL KIT CYLINDER, MG 100 Atlas Copco, art no. 3363 1062 40
- 586750501 — BLADE BUSHING Atlas Copco, art no. 3363 1061 05
- 586752101 — HYDRAULIC CYLINDER INCL. SEAL KIT, MG 100 Atlas Copco, art no. 3363 1061 03
