Husqvarna : BREAKER SB 202 HEAT RESISTANT Part No. 547617301
Part Number: 547 61 73-01 (547617301)
The Husqvarna SB 202 hydraulic breaker (Article 547617301) is engineered for high-performance demolition tasks when paired with Husqvarna DXR remote-controlled demolition robots. This attachment is specifically designed to deliver consistent, high-impact knocking force, facilitating efficient material removal in demanding construction environments.
Key Specifications:
- Model: SB 202
- Article Number: 547 61 73-01
- Compatibility: Husqvarna DXR series
- Feature: Heat resistant construction
| Hydraulics | |
|---|---|
| Hydraulic oil flow | 17.43 gal/min |
| Product data | |
| Impact frequency | 30 Hz |
| Impact energy | 406 Joule |
| Incoming pressure, max | 2,175 psi |
| Operating pressure, max | 2,175 psi |
| Dimensions | |
| Product size length | 63 in |
| Product size width | 16.1 in |
| Product size height | 13.8 in |
| Weight | 492 lbs |
| Packaging length (Calc) | 70.079 in |
| Packaging width (Calc) | 13.78 in |
| Packaging height (Calc) | 12.205 in |
| Article gross weight (Calc) | 489.426 lbs |
- 576636802 — BLADE BUSHING BUSHING COMPLETE ATLAS COPCO ATR.NO 3315 3540 80
- 576636902 — LOCKING PIN LOCK PIN ATLAS COPCO ART.NO 3315 1350 00
- 576637002 — RETAINER TOOL RETAINER ATLAS COPCO ART.NO 3315 1349 00
- 522667901 — SCREW EHHM 16X50 M6S 8.8 ZJSV
- 522487301 — WASHER NORDLOCK NL16
- 522667501 — SCREW EHHM 16X80 M6S 8.8 ZJSV
- 522482401 — BREAKER SB 202
- 580902101 — BREAKER SB 202 Heat resistant
- 589016701 — ADAPTER STRAIGHT O: 1-3/16 - G: 1/2 DUNLOP 1208000
- 585485304 — HOSE ASSY 1-3/16", 3/4", 1-3/16", ORFS L=1460mm
- 589017101 — ADAPTER STRAIGHT O: 1-3/16 - G: 3/4 DUNLOP 1206955
- 510268101 — QUICK COUPLING 3/4" FEMALE PLT4.2519.112
- 597106501 — ADAPTER PLATE COMPL SB 202 WELD ASSY
- 522669701 — LOCK NUT M16 NYLOC BLACK CHROMATED
- 510268001 — QUICK COUPLING 3/4" MALE PLK4.2519.113
- 589010901 — ADAPTER STRAIGHT O: 9/16 - G: 1/4 DUNLOP 1206956
- 585484211 — HOSE ASSY 9/16", 1/4", 9/16", ORFS L=1475mm
- 510267801 — QUICK COUPLING 1/4" MALE PLT1.0606.003
- 576637102 — SEAL SEAL KIT ATLAS COPCO ART.NO 3315 2870 90
- 595082201 — MOIL POINT Moil point (conical) SB 202 SB 202 | 630 mm
- 595082202 — MOIL POINT Moil point (X-Profile) SB 202 SB 202 | 900 mm
- 522869506 — MOIL POINT Extra Long | SB 202
- 595082401 — CHISEL Chisel (cross) SB 202 SB 202
- 522869503 — WIDE CHISEL WIDE CHISEL ATLAS COPCO (SB 22) SB 202
- 501721203 — WEAR PROTECTION PLASTIC SPIRAL 32mm BLACK L=1300mm
- 501739602 — WEAR PROTECTION PLASTIC SPIRAL 20mm BLACK L=1300mm
- 590152502 — BUSHING PAD SB 202
- 592946501 — LOCK BUFFER Atlas Copco art. 3315 1419 00
- 585543101 — HOSE ASSY 1-3/16", 3/4", 1-3/16", ORFS, HEAT COVER L=1460mm
- 576636903 — LOCKING PIN LOCK PIN FOR HEAT RESISTANT SB202
- 586498502 — LOCKING PIN FOR HEAT RESISTANT SB302
- 586501002 — MOIL POINT Epiroc 3363120265 SB 302 | 760 mm
- 586702602 — HEAT PROTECTION KIT SB 202
- 586702802 — HEAT PROTECTION KIT SB 302
- 589011001 — ADAPTER STRAIGHT O: 9/16 - G: 3/8 DUNLOP 1206957
- 536193001 — QUICK COUPLING AIR, MALE, INT G3/8" CEJN 320 eSafe 103205204
- 585543201 — HOSE ASSY 9/16", 1/4", 9/16", ORFS, HEAT COVER L=1475mm
- 536196201 — COVER DUST CAP FEMALE CEJN 09 345 1000
- 583807201 — DUST REDUCTION SB 152
- 583807202 — DUST REDUCTION SB 202/302
- 585484210 — HOSE ASSY 9/16", 1/4", 9/16", ORFS L=1420mm
- 501739603 — WEAR PROTECTION PLASTIC SPIRAL 20mm BLACK L=1500mm
- 582779901 — ADAPTER STRAIGHT O: 9/16 - O: 9/16 Dunlop 1207586
- 582035001 — ADAPTER STRAIGHT Int. G 1/4 - Int. O 9/16 DUNLOP 1216248
- 501720901 — WASHER RUBBER-STEEL 1/4" DUNLOP 1221809
- 531118354 — NIPPLE 18110 with net
- 582780001 — NOZZLE WATER OUTLET SB BREAKERS ATLAS COPCO ART 3315 3952 00
595082401
Chisel cross
522869503
Chisel wide
595082201
Chisel moil point
595082202
Chisel moil point
583807202
Dust reduction kit hydraulic tools
586702601
Heat protection attachment kit – DXR Tools
