Graco | 563263 Reset Indicator with Memory, 3500 psi (241 bar), 1/8 NPSF with O-Ring for MSP, MXP, and MHH Divider Valves
Minimum Order Notice
Graco: $400 minimum order
Graco
Model: 563263
Provides clear information regarding blocked lines, high system pressure, or blocked bearings.
- Offers a rapid troubleshooting tool with visual feedback.
- Requires no tools for reset and no replacement parts after indication.
- Supplies straightforward information on blocked lines, high system pressure, or blocked bearings.
- Lubriquip part number: 509-932-840.
Operational Specifications
| Specification | Value |
|---|---|
| UPC Product | 633955331822 |
| Division | LED |
| Height | .55 IN | 1.397 CM |
| Length | .55 IN | 1.397 CM |
| Width | 2.4 IN | 6.096 CM |
| Volume | 0 FT3 | 0.000 M3 |
| Shipping Weight | .11 LBS | 0.050 KG |
Technical Specifications
| Specification | Value |
|---|---|
| Maximum Working Pressure (bar) | 241 |
| Maximum Working Pressure (kPa) | 24100 |
| Maximum Working Pressure (psi) | 3500 |
| Maximum Working Pressure (MPa) | 24 |
| Model | Trabon |
| For Use With | MSP, MXP, and MHH Divider Valves |
