MI-T-M HS-4004-0MGV HS Series Gasoline Belt Drive
This mobile pressure washer is designed for trailer or truck-bed mounting to handle heavy-duty cleaning tasks. It features a belt-drive system to reduce pump vibration and extend service life.
- Pressure4000psi
- Flow3.7gpm
- Engine408cc
- Net Weight587.00lbs.
01Features & Build
-
Pump
- External bypass system prevents heat accumulation
- Factory-preset unloader valve
- Forged brass manifold construction
- 80-mesh stainless-steel inlet water strainer
-
Frame
- Powder-coated heavy-duty steel chassis
-
Components
- Dual cogged belt drive system
- Burner compatible with No. 1 or No. 2 diesel or kerosene (not bio-fuel compatible)
- 1/2-inch schedule 80 coil with stainless-steel wrap
-
Miscellaneous
- Maximum temperature rise of 150°F/66°C above ambient with 200°F maximum outlet temperature
02Specifications13
| PSI | 4000 |
|---|---|
| GPM | 3.7 |
| Displacement/ Engine | 408cc Vanguard OHV |
| Pump | General |
| Engine Fuel Tank Capacity | 1.51 gallon |
| Burner Fuel Tank Capacity | 10.0 gallons |
| Burner Fuel Cons. | 2.45 gph |
| BTU Per Hour | 343,000 |
| Net Weight | 587.00 lbs. |
| Shipping Weight | 706.00 lbs. |
| Length | 53.00 in. |
| Width | 28.50 in. |
| Height | 42.00 in. |
Specifications are supplied by the manufacturer and are subject to change without notice.
03What’s Included3
- Quick connect nozzles – 0°, 15°, 25° and 40°
- 50-foot x 3/8-inch steel wire-braided hose
- Adjustable pressure insulated dual lance with trigger gun
04Optional Accessories1
- HX-0146Hour Meter. Displays the number of hours unit has been in operation
Factory-installed options — these must be ordered together with the machine and cannot be added after the unit ships. Contact us before checkout to add them to your build.
05Warranty
- 7 YearGeneral Pump
- 3 YearCoil
- 3 YearVanguard Engine
Warranty is provided by the manufacturer and begins at the date of purchase. Registration may be required — see the product manual for full terms and exclusions.
06Documents & Downloads2
07Shipping & Ordering
This unit ships crated with a shipping weight of 706.00 lbs. Freight is quoted to the delivery address.
Need a volume price, a fleet configuration, or help matching this machine to your application? Call us and we’ll spec it with you.
