Husqvarna : SB 202 HYD BREAKER w/ATTCHMENT Part No. 522482401

$18,666.68

Part Number: 522 48 24-01 (522482401)

The Husqvarna SB 202 hydraulic breaker (Article 522482401 / 522 48 24-01) is engineered for integration with Husqvarna DXR demolition robots. This attachment is designed to deliver high-impact knocking force, facilitating efficient material removal and structural demolition tasks in demanding construction environments.

Hydraulics
Hydraulic oil flow	17.43 gal/min
Product data
Impact frequency	30 Hz
Impact energy	406 Joule
Incoming pressure, max	2,175 psi
Operating pressure, max	2,175 psi
Factory option	Standard
Dimensions
Product size length	51.1 in
Product size width	16.1 in
Product size height	13.8 in
Weight	463 lbs
Packaging length (Calc)	47.244 in
Packaging width (Calc)	31.496 in
Packaging height (Calc)	21.654 in
Article gross weight (Calc)	529.109 lbs

576636802 — BLADE BUSHING BUSHING COMPLETE ATLAS COPCO ATR.NO 3315 3540 80
576636902 — LOCKING PIN LOCK PIN ATLAS COPCO ART.NO 3315 1350 00
576637002 — RETAINER TOOL RETAINER ATLAS COPCO ART.NO 3315 1349 00
522667901 — SCREW EHHM 16X50 M6S 8.8 ZJSV
522487301 — WASHER NORDLOCK NL16
522667501 — SCREW EHHM 16X80 M6S 8.8 ZJSV
522482401 — BREAKER SB 202
580902101 — BREAKER SB 202 Heat resistant
589016701 — ADAPTER STRAIGHT O: 1-3/16 - G: 1/2 DUNLOP 1208000
585485304 — HOSE ASSY 1-3/16", 3/4", 1-3/16", ORFS L=1460mm
589017101 — ADAPTER STRAIGHT O: 1-3/16 - G: 3/4 DUNLOP 1206955
510268101 — QUICK COUPLING 3/4" FEMALE PLT4.2519.112
597106501 — ADAPTER PLATE COMPL SB 202 WELD ASSY
522669701 — LOCK NUT M16 NYLOC BLACK CHROMATED
510268001 — QUICK COUPLING 3/4" MALE PLK4.2519.113
589010901 — ADAPTER STRAIGHT O: 9/16 - G: 1/4 DUNLOP 1206956
585484211 — HOSE ASSY 9/16", 1/4", 9/16", ORFS L=1475mm
510267801 — QUICK COUPLING 1/4" MALE PLT1.0606.003
576637102 — SEAL SEAL KIT ATLAS COPCO ART.NO 3315 2870 90
595082201 — MOIL POINT Moil point (conical) SB 202 SB 202 | 630 mm
595082202 — MOIL POINT Moil point (X-Profile) SB 202 SB 202 | 900 mm
522869506 — MOIL POINT Extra Long | SB 202
595082401 — CHISEL Chisel (cross) SB 202 SB 202
522869503 — WIDE CHISEL WIDE CHISEL ATLAS COPCO (SB 22) SB 202
501721203 — WEAR PROTECTION PLASTIC SPIRAL 32mm BLACK L=1300mm
501739602 — WEAR PROTECTION PLASTIC SPIRAL 20mm BLACK L=1300mm
590152502 — BUSHING PAD SB 202
592946501 — LOCK BUFFER Atlas Copco art. 3315 1419 00
585543101 — HOSE ASSY 1-3/16", 3/4", 1-3/16", ORFS, HEAT COVER L=1460mm
576636903 — LOCKING PIN LOCK PIN FOR HEAT RESISTANT SB202
586498502 — LOCKING PIN FOR HEAT RESISTANT SB302
586501002 — MOIL POINT Epiroc 3363120265 SB 302 | 760 mm
586702602 — HEAT PROTECTION KIT SB 202
586702802 — HEAT PROTECTION KIT SB 302
589011001 — ADAPTER STRAIGHT O: 9/16 - G: 3/8 DUNLOP 1206957
536193001 — QUICK COUPLING AIR, MALE, INT G3/8" CEJN 320 eSafe 103205204
585543201 — HOSE ASSY 9/16", 1/4", 9/16", ORFS, HEAT COVER L=1475mm
536196201 — COVER DUST CAP FEMALE CEJN 09 345 1000
583807201 — DUST REDUCTION SB 152
583807202 — DUST REDUCTION SB 202/302
585484210 — HOSE ASSY 9/16", 1/4", 9/16", ORFS L=1420mm
501739603 — WEAR PROTECTION PLASTIC SPIRAL 20mm BLACK L=1500mm
582779901 — ADAPTER STRAIGHT O: 9/16 - O: 9/16 Dunlop 1207586
582035001 — ADAPTER STRAIGHT Int. G 1/4 - Int. O 9/16 DUNLOP 1216248
501720901 — WASHER RUBBER-STEEL 1/4" DUNLOP 1221809
531118354 — NIPPLE 18110 with net
582780001 — NOZZLE WATER OUTLET SB BREAKERS ATLAS COPCO ART 3315 3952 00
