Husqvarna : GRAPPLER TOOL ASSY MG200 Part No. 586743001
Part Number: 586 74 30-01 (586743001)
The Husqvarna MG 200 (Article 586743001) is a multi-grapple attachment engineered for high-efficiency demolition and material handling. Designed with a focus on optimizing the power-to-weight ratio, this unit provides a low operating weight while maintaining a high gripping volume to maximize loading performance.
Constructed for durability in demanding environments, the grapple features components and wear parts manufactured from high-strength carbon steel. The system includes a hydraulic rotary drive for precise positioning and replaceable blades to ensure long-term serviceability and reduced downtime.
| Hydraulics | |
|---|---|
| Hydraulic oil flow | 6.6 gal/min |
| Product data | |
| Rotation angle | 360 ° |
| Incoming pressure, max | 4,351 psi |
| Operating pressure, max | 3,626 psi |
| Dimensions | |
| Jaw depth | 13.2 in |
| Jaw width | 17.7 in |
| Jaw opening, min | 0 in |
| Jaw opening, max | 35.4 in |
| Volume | 18.5 gal (US) |
| Product size length | 38.1 in |
| Product size width | 32.2 in |
| Product size height | 17.7 in |
| Weight | 373 lbs |
| Packaging length (Calc) | 47.244 in |
| Packaging width (Calc) | 31.496 in |
| Packaging height (Calc) | 29.331 in |
| Article gross weight (Calc) | 551.156 lbs |
- 501721202 — WEAR PROTECTION PLASTIC SPIRAL 32mm BLACK L=1450mm
- 510268101 — QUICK COUPLING 3/4" FEMALE PLT4.2519.112
- 586767201 — ADAPTER SOG 1112
- 585542206 — HOSE ASSY 11/16", 3/8", 11/16", ORFS L=1315mm
- 589015401 — ADAPTER STRAIGHT O: 11/16 - G: 3/8 DUNLOP 1207574
- 510268001 — QUICK COUPLING 3/4" MALE PLK4.2519.113
- 576373401 — QUICK COUPLING FEMALE 3/8" PLT1.1310.002
- 588991801 — HOSE ASSY 11/16", 45°, 1/4", 11/16", ORFS L=1505mm
- 501603001 — ADAPTER STRAIGHT O: 11/16 - G: 1/4 DUNLOP 1207575
- 576373201 — QUICK COUPLING 3/8" MALE PLK4.1310.113
- 522669701 — LOCK NUT M16 NYLOC BLACK CHROMATED
- 522671901 — WASHER 17X30X3 BRB HB200 ZJSV
- 588611901 — ADAPTER PLATE COMPL MG 200 WELD ASSY
- 586164102 — SCREW EHHM SS-ISO 4014/4017 M16x40 8.8 Zink-Nickel Black
- 586754101 — SEAL KIT ROTOR, MG 200 Atlas Copco, art no. 3363 1062 42
- 587238201 — SCREW EHHM M16x65 8.8 FZB
- 586754301 — HYDRAULIC CYLINDER INCL. SEAL KIT, MG 200 Atlas Copco, art no. 3363 1060 64
- 586755101 — BLADE BUSHING Atlas Copco, art no. 3363 1060 32
- 586754801 — WEAR PLATE KIT, MG 200 Atlas Copco, art no. 3363 1060 52
- 586753901 — SEAL KIT CYLINDER, MG 200 Atlas Copco, art no. 3363 1062 41
- 586743001 — GRAPPLER MG 200
