Graco | 287975 Heavy-Duty Cart Mounted AA Spray Package with 30:1 Mix Ratio and De-Icing NXT Air Motor with DataTrak
Graco
Model: 287975
The Xtreme NXT airless sprayer features NXT Air Motor Technology, designed for up to 10 times longer service life compared to its predecessor, the Graco King. This sprayer is engineered for demanding protective coatings and corrosion control applications. It includes an accessible modular air valve, a de-icing feature, and reduced noise levels. A variety of models and configurations are available to meet specific pressure and output requirements for high-performance coatings spraying.
Choose the Xtreme Sprayer package that suits your demanding spraying applications.
-
NXT Air Motor
- Modular design for simplified maintenance
- Durable body armor resists rust and dents
- Advanced technology
-
DataTrak Control
- Runaway protection
- Pump diagnostics
- Monitors material usage
- Optional accessory available
-
Modular Air Valve
- De-icing control minimizes icing
- Operates up to 50% quieter than previous models
- Modular design reduces stalling and facilitates easy repair
-
Quick Disconnect
- Simplifies service procedures
-
Graco Xtreme Pump Lower with Built-In Filter
- Reduces overall ownership costs
- Extended rod life with Chromex coating
- Enables quick knockdown
Operational Specifications
| Specification | Value |
|---|---|
| UPC Product | 633955133747 |
| Division | CED |
| Height | 60 IN | 152.400 CM |
| Length | 39.6 IN | 100.584 CM |
| Width | 31.2 IN | 79.248 CM |
| Volume | 42.9 FT3 | 1.215 M3 |
| Shipping Weight | 308 LBS | 139.706 KG |
Technical Specifications
| Specification | Value |
|---|---|
| Convertible | Non-Convertible |
| Fluid Inlet Size (in) | 1-1/4 |
| Fluid Inlet Size (mm) | 31.75 |
| Fluid Outlet Size (mm) | 12.7 |
| Frame Configuration | Heavy-Duty Cart |
| Hose Inlet Diameter (cm) | 0.9525 |
| Hose Inlet Diameter (in) | 3/8 |
| Hose Inlet Diameter (mm) | 9.525 |
| Includes | De-Icing Motor, Heavy Duty Cart, G40 Spray Gun, Hose |
| Maximum Sound Pressure Level (dB(A)) | 83 |
| Maximum Working Pressure (psi) | 3150 |
| Maximum Working Pressure (kPa) | 21704 |
| Pressure Control Type | Air Regulator |
| Overall Width (mm) | 653.3 |
| Model | King |
| Maximum Working Pressure (bar) | 217 |
| Overall Height (cm) | 116.8 |
| Overall Height (in) | 46 |
| Weight (kg) | 103 |
| Overall Height (mm) | 1168.4 |
| Overall Width (in) | 25.72 |
| Overall Width (cm) | 65.3 |
| Outlet Paint Filter | 60 Mesh |
| Pump Rod Type | Chromex |
| Number of Guns | 1 |
| Gun Model | G40 |
| Product Type | Single Leg |
| Material Application | Paints, Primers |
| Air Inlet Thread Gender | Female |
| Air Inlet Size (in) | 0.75 |
| Fluid Inlet Thread Gender | Male |
| Lower Type | Integrated Filter |
| Package Pressure Ratio (Motor/Lower) | 30:1 XL3400 / 220cc |
| Overall Depth (in) | 28 |
| Overall Depth (mm) | 711.2000 |
| Overall Depth (cm) | 71.1200 |
| Approved for Hazardous Locations | Yes |
