HiP | 20-15LF12 Three Way Valve 20,000 psi (2015LF12)

HiP | High Pressure Equipment, Part Number: 20-15LF12

Graco, Part Number: 2015LF12

Features:

Non-rotating stem tips
Packing below stem threads
Type 316 ss high tensile bodies
Positive gland lock device
No stem adjustment needed
Packing is Teflon (450°F) standard with optional Viton (350°F), BUNA-N (200°F) and Grafoil (800°F) available at no additional cost.

Specifications:

Tubing	psi	Connection	Orifice
3/4" O.D.	20,000	LF12	7/16"

For Drawings and Dimensions:

HiP_medium_pressure_valves_fittings_tubing.pdf
